| Type |
Liquid-cooled, 4 valve, DOHC, single-cylinder |
| Capacity |
398.15 cc |
| Bore |
89.0 mm |
| Stroke |
64.0 mm |
| Compression |
12:1 |
| Max Power EC |
40 PS / 39.5 bhp (29.4 kW) @ 8,000 rpm |
| Max Torque EC |
37.5 Nm @ 6,500 rpm |
| System |
Bosch electronic fuel injection with electronic throttle control |
| Exhaust |
Stainless twin-skin header system with stainless steel silencer |
| Final Drive |
X-ring chain |
| Clutch |
Wet, multi-plate, slip & assist |
| Gearbox |
6 speed |
| Frame |
Hybrid spine/perimeter, tubular steel, bolt-on rear subframe |
| Swingarm |
Twin-sided, cast aluminium alloy |
| Front Wheel |
Cast aluminium alloy 10 spoke, 19 x 2.5 in |
| Rear Wheel |
Cast aluminium alloy 10 spoke, 17 x 3.5 in |
| Front Tyre |
100/90-19 |
| Rear Tyre |
140/80-17 |
| Front Suspension |
43mm upside down Big Piston forks. 150mm wheel travel |
| Rear Suspension |
Gas monoshock RSU with external reservoir and pre-load adjustment. 150mm wheel travel |
| Front Brakes |
320mm fixed disc, four-piston radial caliper, ABS |
| Rear Brakes |
230mm fixed disc, ByBreTM single piston floating caliper, ABS |
| Instrument Display and Functions |
Analogue speedometer with integrated multi-function LCD screen |
| Width Handlebars |
901 mm |
| Height Without Mirror |
1169 mm |
| Seat Height |
835 mm |
| Wheelbase |
1418 mm |
| Rake |
23.2 º |
| Trail |
108 mm |
| Tank Capacity |
13 L |
| Wet Weight |
179 kg |
| CO2 Figures |
83.8 g/km EURO 5 CO2 emissions and fuel consumption data are measured according to regulation 168/2013/EC. Figures for fuel consumption are derived from specific test conditions and are for comparative purposes only. They may not reflect real driving results. |
| Service Interval |
10,000 miles (16,000km)/12 months (whichever comes first) |
