2023: Suzuki LT-A500 Power Steering

  • Sale
  • Regular price $19,500.00
Tax included. Shipping calculated at checkout.

2023 LT-A500 just arrived.

Power steering model.

Add the farm kit for another $750 including gst.

Bull bars, dog mat, tow ball, mud flaps and filter sock for fuel tank.



Engine Type 4-stroke, liquid-cooled, OHC
Engine Displacement (CC) 493
Bore x Stroke 87.5 mm x 82.0 mm
Transmission CVT Automatic
Fuel System Fuel Injection
Starter System Electric
Overall Length (mm) 2190
Overall Width (mm) 1275
Overall Height (mm) 1285
Wheelbase (mm) 1285
Ground Clearance (mm) 260
Seat Height (mm) 920
Curb Mass (kg) 326
Suspension - Front Independent, double wishbone, coil spring, oil damped
Suspension - Rear Independent, double wishbone, coil spring, oil damped
Brakes - Front Disc brake, twin
Brakes - Rear Sealed oil-bathed multi-disc
Tyre - Front AT25 × 8-12**, tubeless
Tyre - Rear AT25 × 10-12**, tubeless
Fuel Tank Capacity (L) 17.5




  • Increased towing capacity (450kg -> 600kg)
  • New frame, with 25% thicker frame tubing (was 1.6mm, now 2.0mm)
  • Updated front and rear suspension, stabiliser, front and rear brakes and power steering
  • Trailer hitch mount has changed to a square-receiver type
  • Newly design multi-function instrument panel with service reminder icon
  • Expansive storage compartments including a front waterproof storage and two rear storage compartments
  • Handlebar-mounted headlight
  • Flush-mount, LED-style taillight
  •  range of Genuine Suzuki Accessories


  • Dual front hydraulic disc brakes with 190mm rotors
  • Sealed, oil-bath multidisc rear brake with 106mm discs


  • Updated power steering
  •  rear stabiliser system
  •  independent suspension system
  • Updated shock absorbers with new damping force tuning.
  • Long suspension travel
  • Front wheel travel 172mm
  • Rear wheel travel 194mm

T&C’s: Price excludes GST. Finance offer based on new Suzuki KingQuad LT-A500XP from 23/05/22 – 31/08/22, or while stocks last. The offer is based on 4.99% interest rate over 24 months and an up-front payment of one third of the MRP ($6,044 INC GST), $305 documentation fee and $10.35 PPSR; a further payment of one third to be paid in 12 months ($6,609.40 INC GST); and a final payment of one third in 24 months ($6,609.40 INC GST). Total amount payable $19,262.80 INC GST. Normal UDC lending and credit criteria apply. Excludes demo units and all other promotion. Free heated grips and front box offer limit has been reached, and no longer applies to the remainder of the promotional period.
